Flangia d. refrigerante

A1 (8X1, 8XK)5

• 1.0 TFSI 70 kW · 95 CV2015–2018CHZB, DKLD
• 1.0 TFSI 60 kW · 82 CV2016–2018CHZE
• 1.4 TFSI 103 kW · 140 CV2012–2015CPTA
• 1.4 TFSI 92 kW · 125 CV2014–2018CZCA, CZDD
• 1.4 TSI 110 kW · 150 CV2014–2018CZEA

A1 Sportback (8XA, 8XF)5

• 1.0 TFSI 70 kW · 95 CV2015–2018CHZB, DKLD
• 1.0 TFSI 60 kW · 82 CV2016–2018CHZE
• 1.4 TFSI 103 kW · 140 CV2012–2015CPTA
• 1.4 TFSI 92 kW · 125 CV2014–2018CZCA, CZDD
• 1.4 TSI 110 kW · 150 CV2014–2018CZEA

A1 Sportback (GBA)2

• 25 TFSI 70 kW · 95 CV2018–oggiDKLA, DUSB, DLAC
• 30 TFSI 85 kW · 116 CV2018–oggiDKJA, DKRF, DUSA

A3 (8V1, 8VK)7

• 1.0 TFSI 85 kW · 115 CV2016–2017CHZD
• 1.2 TFSI 77 kW · 105 CV2013–2015CJZA
• 1.2 TFSI 81 kW · 110 CV2014–2016CYVB
• 1.4 TFSI 90 kW · 122 CV2012–2014CXSA, CMBA
• 1.4 TFSI 103 kW · 140 CV2013–2016CPTA
• 1.4 TFSI 92 kW · 125 CV2014–2016CZCA, CXSB
• 1.4 TSI 110 kW · 150 CV2014–2017CZEA

A3 Cabriolet (8V7, 8VE)1

• 1.4 TFSI 85 kW · 115 CV2016–2020CZCC

A3 Limousine (8VS, 8VM)7

• 1.0 TFSI 85 kW · 115 CV2016–2020CHZD
• 1.2 TFSI 77 kW · 105 CV2013–2015CJZA
• 1.2 TFSI 81 kW · 110 CV2014–2016CYVB
• 1.4 TFSI 103 kW · 140 CV2013–2016CPTA
• 1.4 TFSI 90 kW · 122 CV2013–2020CXSA
• 1.4 TFSI 92 kW · 125 CV2013–2016CZCA, CXSB
• 1.4 TSI 110 kW · 150 CV2014–2020CZEA

A3 Sportback (8VA, 8VF)8

• 1.0 TFSI 85 kW · 115 CV2016–2020CHZD, DKRF
• 1.2 TFSI 77 kW · 105 CV2013–2015CJZA
• 1.2 TFSI 81 kW · 110 CV2014–2016CYVB
• 1.4 TFSI 90 kW · 122 CV2012–2020CXSA, CMBA
• 1.4 TFSI 103 kW · 140 CV2013–2014CPTA
• 1.4 TFSI 92 kW · 125 CV2014–2016CZCA, CXSB
• 1.4 TFSI g-tron 81 kW · 110 CV2013–2020CPWA
• 1.4 TSI 110 kW · 150 CV2014–2020CZEA

A4 B9 (8W2, 8WC)1

• 1.4 TFSI 110 kW · 150 CV2015–2019CVNA

A4 B9 Avant (8W5, 8WD)1

• 1.4 TFSI 110 kW · 150 CV2016–2019CVNA

A5 (F53, F5P)1

• 1.4 TFSI 110 kW · 150 CV2016–2020CVNA

A5 Sportback (F5A, F5F)1

• 1.4 TFSI 110 kW · 150 CV2017–2020CVNA

Q2 (GAB, GAG)3

• 1.0 TFSI 85 kW · 115 CV2016–2020CHZJ
• 1.4 TFSI 110 kW · 150 CV2016–oggiCZEA
• 30 TFSI 85 kW · 116 CV2018–oggiDKRF, DUSA

Q3 (8UB, 8UG)2

• 1.4 TFSI 92 kW · 125 CV2016–2018CZDB
• 1.4 TSI 110 kW · 150 CV2013–2018CZEA, CZDA, CHPB

ALHAMBRA (710, 711)1

• 1.4 TSI 110 kW · 150 CV2015–2022CZDA, DJKA

ARONA (KJ7, KJP)1

• 1.0 TSI 70 kW · 95 CV2017–oggiDUSB, CHZL, DKLA, DLAC

ATECA (KH7, KHP)3

• 1.0 TSI 85 kW · 116 CV2016–oggiDUSA, DKRF, CHZJ
• 1.4 TSI 110 kW · 150 CV2016–oggiDJKA, CZEA
• 1.4 TSI 4Drive 110 kW · 150 CV2016–oggiCZEA

IBIZA IV SC (6J1, 6P5)6

• 1.0 TSI 70 kW · 95 CV2015–2016CHZB
• 1.0 TSI 81 kW · 110 CV2015–2016CHZC
• 1.2 TSI 66 kW · 90 CV2015–2016CJZC
• 1.2 TSI 81 kW · 110 CV2015–2016CJZD
• 1.4 TSI 103 kW · 140 CV2013–2015CPTA
• 1.4 TSI 110 kW · 150 CV2015–2016CZEA

IBIZA IV ST (6J8, 6P8)6

• 1.0 TSI 70 kW · 95 CV2015–2016CHZB
• 1.0 TSI 81 kW · 110 CV2015–2016CHZC
• 1.2 TSI 66 kW · 90 CV2015–2016CJZC
• 1.2 TSI 81 kW · 110 CV2015–2016CJZD
• 1.4 TSI 103 kW · 140 CV2013–2015CPTA
• 1.4 TSI 110 kW · 150 CV2015–2016CZEA

IBIZA V (KJ1, KJG)3

• 1.0 TGI 66 kW · 90 CV2017–oggiDBYA
• 1.0 TSI 70 kW · 95 CV2017–oggiDUSB, CHZL, DKLA, DLAC
• 1.0 TSI 85 kW · 116 CV2017–oggiDUSA, DKJA, DKRF, CHZJ

LEON (5F1)9

• 1.0 TSI 85 kW · 115 CV2015–2020CHZD, DKRF
• 1.2 TSI 63 kW · 86 CV2012–2018CYVA, CJZB
• 1.2 TSI 77 kW · 105 CV2013–2020CJZA
• 1.2 TSI 81 kW · 110 CV2014–2020CYVB
• 1.4 TGI 81 kW · 110 CV2013–2018CPWA
• 1.4 TSI 90 kW · 122 CV2012–2016CMBA, CXSA
• 1.4 TSI 103 kW · 140 CV2012–2020CHPA, CPTA
• 1.4 TSI 92 kW · 125 CV2014–2020CZCA
• 1.4 TSI 110 kW · 150 CV2014–2020CZDA, CZEA

LEON SC (5F5)1

• 1.0 TSI 85 kW · 115 CV2015–2018CHZD

LEON ST (5F8)9

• 1.0 TSI 85 kW · 115 CV2015–2020CHZD, DKRF
• 1.2 TSI 77 kW · 105 CV2013–2020CJZA
• 1.2 TSI 63 kW · 86 CV2013–2018CYVA, CJZB
• 1.2 TSI 81 kW · 110 CV2014–2020CYVB
• 1.4 TGI 81 kW · 110 CV2013–2018CPWA
• 1.4 TSI 90 kW · 122 CV2012–2015CMBA, CXSA
• 1.4 TSI 103 kW · 140 CV2013–2020CHPA, CPTA
• 1.4 TSI 92 kW · 125 CV2014–2018CZCA
• 1.4 TSI 110 kW · 150 CV2014–2020CZEA

TOLEDO IV (KG3)5

• 1.0 TSI 70 kW · 95 CV2017–2019DKLD, CHZB
• 1.0 TSI 81 kW · 110 CV2017–2019DKRC, CHZC
• 1.2 TSI 66 kW · 90 CV2015–2017CJZC
• 1.2 TSI 81 kW · 110 CV2015–2017CJZD
• 1.4 TSI 92 kW · 125 CV2015–2019CZCA

FABIA III (NJ3)6

• 1.0 TSI 70 kW · 95 CV2014–2021CHZB, DKLD
• 1.0 TSI 81 kW · 110 CV2014–2021DKRC, CHZC
• 1.2 TSI 66 kW · 90 CV2014–2021CJZC
• 1.2 TSI 81 kW · 110 CV2014–2021CJZD
• 1.4 TSI R5 92 kW · 125 CV2018–2021CZCA
• 1.6 81 kW · 110 CV2015–2021CWVA

FABIA III Familiare (NJ5)5

• 1.0 TSI 70 kW · 95 CV2014–2022CHZB, DKLD
• 1.0 TSI 81 kW · 110 CV2014–2022DKRC, CHZC
• 1.2 TSI 66 kW · 90 CV2014–2022CJZC
• 1.2 TSI 81 kW · 110 CV2014–2022CJZD
• 1.6 81 kW · 110 CV2015–2022CWVA

KAROQ (NU7, ND7)1

• 1.0 TSI 85 kW · 116 CV2017–oggiCHZJ, DKRF, DUSA

KODIAQ I (NS6, NS7, NV7)3

• 1.4 TSI 92 kW · 125 CV2016–oggiCZCA, CZDB
• 1.4 TSI 110 kW · 150 CV2016–oggiCZEA, CZDA
• 1.4 TSI 4x4 110 kW · 150 CV2016–oggiCZEA, CZDA

OCTAVIA III (5E3, NL3, NR3)8

• 1.0 TSI 85 kW · 115 CV2016–2020DKRF, DKRA, CHZD
• 1.2 TSI 63 kW · 86 CV2012–2017CYVA, CJZB
• 1.2 TSI 77 kW · 105 CV2012–2017CJZA
• 1.2 TSI 81 kW · 110 CV2015–2017CYVB
• 1.4 TSI 103 kW · 140 CV2012–2017CHPA
• 1.4 TSI 110 kW · 150 CV2014–2020CZDA, CHPB
• 1.4 TSI G-TEC 81 kW · 110 CV2013–2017CPWA
• 1.6 81 kW · 110 CV2014–2020CWVA

OCTAVIA III Combi (5E5, 5E6)8

• 1.0 TSI 85 kW · 115 CV2016–2020DKRF, DKRA, CHZD
• 1.2 TSI 63 kW · 86 CV2012–2017CYVA, CJZB
• 1.2 TSI 77 kW · 105 CV2012–2017CJZA
• 1.2 TSI 81 kW · 110 CV2015–2017CYVB
• 1.4 TSI 103 kW · 140 CV2012–2017CHPA
• 1.4 TSI 110 kW · 150 CV2014–2020CZDA, CHPB
• 1.4 TSI G-TEC 81 kW · 110 CV2012–2017CPWA
• 1.6 SRE 81 kW · 110 CV2014–2017CWVA

RAPID (NH3, NK3, NK6)5

• 1.0 TSI 70 kW · 95 CV2017–2019CHZB, DKLD
• 1.0 TSI 81 kW · 110 CV2017–2019DKRC, CHZC
• 1.2 TSI 66 kW · 90 CV2015–2019CJZC
• 1.2 TSI 81 kW · 110 CV2015–2019CJZD
• 1.4 TSI 92 kW · 125 CV2015–2022CZCA

RAPID Spaceback (NH1)5

• 1.0 TSI 70 kW · 95 CV2017–2019CHZB, DKLD
• 1.0 TSI 81 kW · 110 CV2017–2019DKRC, CHZC
• 1.2 TSI 66 kW · 90 CV2015–2019CJZC
• 1.2 TSI 81 kW · 110 CV2015–2019CJZD
• 1.4 TSI 92 kW · 125 CV2015–2019CZCA

SUPERB III (3V3)3

• 1.4 TSI 110 kW · 150 CV2015–2024CZEA, CZDA
• 1.4 TSI 92 kW · 125 CV2015–2024CZCA
• 1.4 TSI 4x4 110 kW · 150 CV2015–2024CZEA

SUPERB III Familiare (3V5)3

• 1.4 TSI 92 kW · 125 CV2015–2024CZCA
• 1.4 TSI 110 kW · 150 CV2015–2024CZEA, CZDA
• 1.4 TSI 4x4 110 kW · 150 CV2015–2024CZEA

CADDY ALLTRACK IV Cassone/Limousine spaziosa (SAA)5

• 1.0 TSI 75 kW · 102 CV2015–2020CHZG
• 1.2 TSI 62 kW · 84 CV2015–2020CYVC
• 1.4 TGI CNG 81 kW · 110 CV2015–2020CPWA
• 1.4 TSI 92 kW · 125 CV2015–2020CZCB
• 1.4 TSI 96 kW · 131 CV2019–2020DJKD

CADDY ALLTRACK IV MPV / Space wagon (SAB)6

• 1.0 TSI 75 kW · 102 CV2015–2020CHZG
• 1.0 TSI 62 kW · 84 CV2018–2019DKRD
• 1.2 TSI 62 kW · 84 CV2015–2020CYVC
• 1.4 TGI CNG 81 kW · 110 CV2015–2020CPWA
• 1.4 TSI 92 kW · 125 CV2015–2020CZCB
• 1.4 TSI 96 kW · 131 CV2018–2020DJKD

CADDY IV Cassone/Limousine spaziosa (SAA, SAH)5

• 1.0 TSI 75 kW · 102 CV2015–2020CHZG, DKRE
• 1.2 TSI 62 kW · 84 CV2015–2020CYVC
• 1.4 TGI CNG 81 kW · 110 CV2015–2020CPWA
• 1.4 TSI 92 kW · 125 CV2015–2020CZCB
• 1.6 SRE 81 kW · 110 CV2015–2020CWVA

CADDY IV MPV / Space wagon (SAB, SAJ)5

• 1.0 TSI 75 kW · 102 CV2015–2020CHZG, DKRE
• 1.2 TSI 62 kW · 84 CV2015–2020CYVC
• 1.4 TGI CNG 81 kW · 110 CV2015–2020CPWA
• 1.4 TSI 92 kW · 125 CV2015–2020CZCB
• 1.6 SRE 81 kW · 110 CV2015–2020CWVA

CC B7 (358)1

• 1.4 TSI 110 kW · 150 CV2015–2016CZDA

GOLF SPORTSVAN VII (AM1, AN1)8

• 1.0 TSI 85 kW · 115 CV2015–2020DKRF, CHZD
• 1.0 TSI 63 kW · 86 CV2017–2019DKLB, CHZK
• 1.0 TSI 81 kW · 110 CV2017–2018CHZC
• 1.2 TSI 81 kW · 110 CV2014–2017CYVB
• 1.2 TSI 63 kW · 86 CV2014–2017CYVA
• 1.4 TSI 110 kW · 150 CV2014–2018CZDA
• 1.4 TSI 92 kW · 125 CV2014–2020CZCA
• 1.4 TSI MultiFuel 92 kW · 125 CV2014–2017CPVB

GOLF VII (5G1, BQ1, BE1, BE2)14

• 1.0 TSI 85 kW · 115 CV2015–2020DKRF, CHZD
• 1.0 TSI 81 kW · 110 CV2016–2020CHZC
• 1.0 TSI 63 kW · 86 CV2017–2019DKLB, CHZK
• 1.2 TSI 63 kW · 86 CV2012–2017CJZB, CYVA
• 1.2 TSI 77 kW · 105 CV2012–2017CJZA
• 1.2 TSI 81 kW · 110 CV2014–2017CYVB
• 1.4 GTE Hybrid 150 kW · 204 CV2014–2020CUKB, DGEA
• 1.4 TGI CNG 81 kW · 110 CV2013–2018CPWA, CZBA
• 1.4 TSI 103 kW · 140 CV2012–2017CPTA, CHPA
• 1.4 TSI 90 kW · 122 CV2012–2017CMBA, CXSA
• 1.4 TSI 92 kW · 125 CV2014–2020CZCA
• 1.4 TSI MultiFuel 90 kW · 122 CV2012–2017CPVA
• 1.4 TSI MultiFuel 92 kW · 125 CV2013–2018CPVB
• 1.6 81 kW · 110 CV2014–2017CWVA

GOLF VII Variant (BA5, BV5)14

• 1.0 TSI 85 kW · 115 CV2015–2020DKRF, CHZD
• 1.0 TSI 81 kW · 110 CV2016–2020CHZC
• 1.0 TSI 63 kW · 86 CV2017–2019DKLB, CHZK
• 1.2 TSI 63 kW · 86 CV2013–2017CJZB, CYVA
• 1.2 TSI 77 kW · 105 CV2013–2020CJZA
• 1.2 TSI 81 kW · 110 CV2014–2017CYVB
• 1.4 TGI CNG 81 kW · 110 CV2013–2018CPWA
• 1.4 TSI 90 kW · 122 CV2013–2017CXSA
• 1.4 TSI 103 kW · 140 CV2013–2020CHPA
• 1.4 TSI 92 kW · 125 CV2014–2020CZCA, CZDD
• 1.4 TSI 110 kW · 150 CV2014–2021CZDA, CHPB
• 1.4 TSI MultiFuel 90 kW · 122 CV2013–2017CPVA
• 1.4 TSI MultiFuel 92 kW · 125 CV2014–2017CPVB
• 1.6 81 kW · 110 CV2014–2017CWVA

JETTA IV (162, 163, AV3, AV2)1

• 1.4 TSI Hybrid 125 kW · 170 CV2011–2017CNLA, CRJA

PASSAT B8 (3G2, CB2)4

• 1.4 GTE Hybrid 160 kW · 218 CV2015–2024DGEB, CUKC
• 1.4 TSI 110 kW · 150 CV2014–2024CZDA, CZEA
• 1.4 TSI 92 kW · 125 CV2014–2018CZCA
• 1.4 TSI 4motion 110 kW · 150 CV2015–2018CZEA

PASSAT B8 Variant (3G5, CB5)4

• 1.4 GTE Hybrid 160 kW · 218 CV2015–2024DGEB, CUKC
• 1.4 TSI 110 kW · 150 CV2014–2024CZDA, CZEA
• 1.4 TSI 92 kW · 125 CV2014–2018CZCA
• 1.4 TSI 4motion 110 kW · 150 CV2015–2018CZEA

POLO V (6R1, 6C1)7

• 1.0 TSI 70 kW · 95 CV2014–2017CHZB
• 1.0 TSI 81 kW · 110 CV2014–2017CHZC
• 1.2 TSI 81 kW · 110 CV2014–2017CJZD
• 1.2 TSI 16V 66 kW · 90 CV2014–2017CJZC
• 1.4 TSI 110 kW · 150 CV2014–2017CZEA
• 1.6 81 kW · 110 CV2014–2017CWVA
• 1.6 66 kW · 90 CV2014–2017CWVB

POLO VI (AW1, BZ1, AE1)2

• 1.0 TGI 66 kW · 90 CV2017–oggiDBYA
• 1.0 TSI 70 kW · 95 CV2017–oggiDKLA, DUSB, CHZL, DXTA, DLAC

SCIROCCO III (137, 138)2

• 1.4 TSI 92 kW · 125 CV2013–2017CZCA, CXSB
• 1.4 TSI 110 kW · 150 CV2015–2017CZDA

SHARAN (7N1, 7N2)1

• 1.4 TSI 110 kW · 150 CV2015–2022CZDA, DJKA

T-ROC (A11, D11)1

• 1.0 TSI 85 kW · 116 CV2017–oggiCHZJ, DKRF, DUSA

TIGUAN (5N_)2

• 1.4 TSI 92 kW · 125 CV2015–2018CZDB
• 1.4 TSI 110 kW · 150 CV2015–2018CZDA

TIGUAN (AD1, AX1)2

• 1.4 TSI 92 kW · 125 CV2016–2022CZCA, CZDB
• 1.4 TSI 4motion 110 kW · 150 CV2016–2018CZDA, CZEA

TIGUAN ALLSPACE (BW2, BJ2)1

• 1.4 TSI 110 kW · 150 CV2017–oggiCZDA, CZEA

TOURAN (5T1)2

• 1.2 TSI 81 kW · 110 CV2015–2018CYVB
• 1.4 TSI 110 kW · 150 CV2015–2022CZDA

UP! (121, 122, BL1, BL2, BL3, 123)2

• 1.0 GTI 85 kW · 115 CV2017–2023DKRA
• 1.0 TSI 66 kW · 90 CV2016–2019CHZA, DKLC
